Page 69 - Oasis Park Residencia Brochure 2020 TR
P. 69
120 Sq. Yds. | Cordoba & Valencia | 5 Room Villas with Basement
HALL
22'-10" x 40'-8"
PLOT
24’ 0”
45’ 0” SKY LIGHT
OPEN
HALL
22'-10" x 40'-8"
UP
PLOT PLOT
U.G.W, TANK
6’ x 7’-6”
1575.0 als,
U. G.W TANK
6’ x 7’-6”
1575.0 als
ROAD
BASEMENT FLOOR PLAN Disclaimer: 1- All dimensions are in imperial and metric, and measured from finish to finish excluding construction tolerances. 2- All materials, dimensions, and drawings are approximate only. 3- Information is
subject to change without notice, at developer’s absolute discretion. 4- Actual area may vary from the stated area. 5- Drawings not to scale. 6. All images used are for illustrative purposes only and do not
represent the actual size, features, specifications, fittings, and furnishings. 7- The developer reserves the right to make revisions / alterations, at it’s absolute discretion, without any liability whatsoever.
